適用于建筑樓宇、醫院、住宅小區、市政工程、道路交通及施工工廠排污、養殖、藥業、飲料、海水鹽水、一般腐蝕性介質中含有的固體顆粒、長纖維廢水、污水。
Suitable for construction buildings, hospitals, residential communities, municipal engineering, road traffic, and construction factory pollution discharge, aquaculture, pharmaceutical industry, beverages, seawater and saline water, solid particles contained in general corrosive media, long fiber wastewater, and sewage.

產品概述：
1、國標法蘭WQ(D)-S全不銹鋼精密鑄造污水污物潛水電泵采用不銹鋼精密鑄造外殼,具有耐腐蝕、環保型、揚程高、(流量大等特點。
2、油室采用氟橡膠雙面機械密封,外室采用單面氟橡膠機械油封結構,有效地減少因骨架油封與軸之間摩擦而造成的密封進水問題。
3、電機采用高溫線, F級絕緣,熱保護裝置，轉子軸全部采用摩擦焊接工藝316接軸，有效地延長泵的使用壽命。
4、根據客戶要求,可帶攪勻裝置,該裝置隨電機軸旋轉產生極強的攪拌力,將污水池內的沉積物攪拌成懸浮物后排出。也可帶切割裝置,能將污水中的長纖維、塑料、紙袋、稻草等雜物碎片后排出。
5、可根據客戶特殊要求定制防腐蝕電纜線、四氟機封,及高溫液體的零件配置。
不銹鋼水泵安裝高度過高，導致葉輪浸入深度不足，導致泵的出水量減少；控制水泵安裝標高的允許偏差，不能隨意擴大。不銹鋼水泵下端的耐磨環磨損嚴重或被雜物堵塞。清理雜物或更換磨損環。
不銹鋼水泵電流過大造成電機過載或超溫的主要原因:
1.工作電壓過低或過高；檢查電源電壓并調整傳輸電壓。
2.泵內動靜件有摩擦或葉輪與密封圈有摩擦；確定摩擦部件的位置，排除故障。
3.低揚程和大流量導致電機功率與泵的特性不一致；調節閥門減少流量，使電機功率與水泵匹配。
 使用條件：
1、以葉輪中心為準,潛入水下深度不得超過5m。
2、輸送介質溫度不高于60°C。
3、輸送介質的PH值304 (1-10),316 (4-14)。

 Product Overview:
1. The national standard flange WQ (D) - S all stainless steel precision casting sewage submersible pump adopts a stainless steel precision casting shell, which has the characteristics of corrosion resistance, environmental protection, high head, and large flow rate.
2. The oil chamber adopts a double-sided mechanical seal made of fluororubber, while the outer chamber adopts a single-sided fluororubber mechanical oil seal structure, effectively reducing the problem of sealing water ingress caused by friction between the skeleton oil seal and the shaft.
3. The motor adopts high temperature wire, F-class insulation, thermal protection device, and all rotor shafts adopt friction welding process 316 coupling, effectively extending the service life of the pump.
4. According to customer requirements, a mixing device can be equipped, which generates extremely strong mixing force with the rotation of the motor shaft, stirring the sediment in the sewage tank into suspended solids and discharging them. It can also be equipped with a cutting device, which can discharge debris such as long fibers, plastic, paper bags, and straw from the sewage.
5. We can customize the configuration of anti-corrosion cables, PTFE machine seals, and high-temperature liquid parts according to customer special requirements.
The installation height of the stainless steel water pump is too high, resulting in insufficient immersion depth of the impeller and a decrease in the pump's water output; The allowable deviation for controlling the installation elevation of the water pump should not be arbitrarily expanded. The wear-resistant ring at the lower end of the stainless steel water pump is severely worn or blocked by debris. Clean up debris or replace worn rings.
The main reasons for motor overload or overheating caused by excessive current in stainless steel water pumps are:
1. The working voltage is too low or too high; Check the power supply voltage and adjust the transmission voltage.
2. There is friction between the moving and stationary parts in the pump or between the impeller and the sealing ring; Determine the position of the friction components and troubleshoot them.
3. Low head and high flow rate result in inconsistent motor power and pump characteristics; Adjust the valve to reduce flow and match the motor power with the water pump.
Usage conditions:
1. Based on the center of the impeller, the depth of submergence shall not exceed 5m.
2. The temperature of the conveying medium shall not exceed 60 ° C.
3. The pH values of the conveying medium are 304 (1-10), 316 (4-14).
