GNWQ型雙絞刀切割潛水電泵系列(絲口款)

該系列電泵是電機和水泵以下泵式結構而成的電力排灌設備，適用工程建筑工地、煤礦、冶金、印染、紡織等場合排灌污水之用，也可用于清水排灌。有些規格采用流道式葉輪，大大提高了水泵的抗堵塞能力；有些規格采用全揚程理論設計使電泵能夠在正常工況下保持無過載運行。有效地延長了電機使用壽命。切割式系列電泵引進，消化吸收了國外先進技術，利用剪切原理進行了新穎獨特的設計，對長纖維、塑料袋等均可切割或撕裂。 This series of electric pump is a motor and pump pump under the pump structure of power drainage and irrigation equipment, suitable for engineering construction site, coal mine, metallurgy, printing and dyeing, textile and other occasions for irrigation and drainage of sewage, can also be used for water drainage and irrigation. Some specifications use runner impeller, which greatly improves the anti-blocking ability of the pump; Some specifications use full head theory design so that the electric pump can maintain no overload operation under normal conditions. The service life of the motor is extended effectively. The introduction of cutting series electric pump, digestion and absorption of foreign advanced technology, the use of shear principle for novel and unique design, long fibers, plastic bags can be cut or torn.

所屬分類：

潛水電泵

排污泵/切割泵

關鍵詞：

排污泵

潛水泵

雙鉸刀切割泵

大功率

在線留言

返回上一頁

性能參數
產品用途
產品尺寸
配件分解圖

- 商品名稱: GNWQ型雙絞刀切割潛水電泵系列(絲口款)
該系列電泵是電機和水泵以下泵式結構而成的電力排灌設備，適用工程建筑工地、煤礦、冶金、印染、紡織等場合排灌污水之用，也可用于清水排灌。有些規格采用流道式葉輪，大大提高了水泵的抗堵塞能力；有些規格采用全揚程理論設計使電泵能夠在正常工況下保持無過載運行。有效地延長了電機使用壽命。切割式系列電泵引進，消化吸收了國外先進技術，利用剪切原理進行了新穎獨特的設計，對長纖維、塑料袋等均可切割或撕裂。 This series of electric pump is a motor and pump pump under the pump structure of power drainage and irrigation equipment, suitable for engineering construction site, coal mine, metallurgy, printing and dyeing, textile and other occasions for irrigation and drainage of sewage, can also be used for water drainage and irrigation. Some specifications use runner impeller, which greatly improves the anti-blocking ability of the pump; Some specifications use full head theory design so that the electric pump can maintain no overload operation under normal conditions. The service life of the motor is extended effectively. The introduction of cutting series electric pump, digestion and absorption of foreign advanced technology, the use of shear principle for novel and unique design, long fibers, plastic bags can be cut or torn.
關鍵詞:
- 排污泵
- 潛水泵
- 雙鉸刀切割泵
- 大功率
切割式潛水排污泵適用于工廠商業嚴重污染廢水的排放、主宅區的污水排污站、城市污水處理廠派水系統、人防系統排水站、自來水廠的給水設備、醫院、賓館的污水排放、市政工程建筑工地、礦山配套附機、農村沼氣池、農田灌溉等行業，輸送帶顆粒的污水，污物，也可用于清水及帶弱腐蝕性介質。

Cutting type submersible sewage pump is suitable for the discharge of commercial seriously polluted wastewater, sewage station in the main house area, urban sewage treatment plant sending water system, civil air defense system drainage station, water supply equipment of the water plant, hospital, hotel sewage discharge, municipal engineering construction site, mine supporting equipment, rural biogas digester, farmland irrigation and other industries, conveyor belt particles of sewage, sewage, It can also be used for clean water and weakly corrosive media.

使用條件：

Conditions of use:

1、排污泵系列產品在額定電壓為380V，電源頻率為50Hz時適用；

Sewage pump series products are applicable when the rated voltage is 380V and the power frequency is 50Hz;

2、介質溫度不超過40攝氏度，介質密度≤1150kg/m3,PH值在5-11范圍之間;

medium temperature does not exceed 40 degrees Celsius, medium density ≤1150kg/m3,PH value in the range of 5-11;

3、海拔高度不超過1000米；

the altitude does not exceed 1000 meters;

4、輸送介質年粘度不超1000CP；

the annual viscosity of the conveying medium is not more than 1000CP;

5、產品工作運行時必須潛入水中，但潛水深度不得超過10m

The product must be submerged in water during operation, but the diving depth shall not exceed 10m.

6、產品材質主要為鑄鐵，不能用于強腐蝕性或含有強腐蝕性的介質中。

the product material is mainly cast iron, can not be used for strong corrosive or containing strong corrosive media.
